Graafwerktuiggehechtheid R220LC-9S 39Q6-12100/de schommelingsversnellingsbak van 39Q6-12101/39Q6-12102-voor Hyundai
Productiebeschrijving
Detailbeeld
| Pos. | Artikelnummer | Qty | Delennaam | Commentaren |
|---|---|---|---|---|
| *. | @ | [1] | SCHOMMELINGSmotor ASSY | ZIE 4115 |
| *-2. | 39Q6-12100 | [1] | HET TOESTEL VAN DE SCHOMMELINGSvermindering | HYMS |
| *-2. | 39Q6-12101 | [1] | HET TOESTEL VAN DE SCHOMMELINGSvermindering | HYMS |
| *-2. | 39Q6-12102 | [1] | HET TOESTEL VAN DE SCHOMMELINGSvermindering | HYMS |
| 1. | 39Q6-12110 | [1] | Toestel-RING | |
| 2. | 39Q6-12121 | [1] | Schacht-AANDRIJVING | |
| 3. | 39Q6-12130 | [1] | Lager-TAPER.MAIN | |
| 4. | 39Q6-12140 | [1] | Lager-VERSMALLING | |
| 5. | 39Q6-12150 | [1] | Noot-RING | |
| 6. | 39Q6-12161 | [1] | Plaat-SLOT | |
| 7. | S017-120166 | [4] | Bout-HEXUITDRAAI | |
| 8. | 39Q6-12171 | [1] | OMHULSEL | |
| 8. | 39Q6-12172 | [1] | OMHULSEL | |
| 9. | S109-100306 | [10] | Bout-CONTACTDOOS | |
| 10. | 39Q6-12190 | [1] | DRAGER 2 | |
| 11. | 39Q6-12200 | [3] | Toestel-PLANETARISCH 2 | |
| 12. | 39Q6-12210 | [6] | Lager-NAALD 2 | |
| 13. | 39Q6-12220 | [6] | Wasmachine-DUW 2 | |
| 14. | 39Q6-12230 | [3] | Speld-DRAGER 2 | |
| 15. | S472-800364 | [3] | De speld-LENTE | |
| 16. | 39Q6-12240 | [1] | Toestel-ZON 2 | |
| 17. | 39Q6-12260 | [1] | DRAGER 1 | |
| 18. | 39Q6-12271 | [3] | Toestel-PLANETARISCH 1 | |
| 19. | 39Q6-12280 | [3] | Lager-NAALD 1 | |
| 20. | 39Q6-12290 | [3] | WASMACHINE-DUW 1, OMHOOG | |
| 21. | 39Q6-12300 | [3] | LAGE WASMACHINE-DUW 1, | |
| 22. | 39Q6-12310 | [3] | Speld-DRAGER 1 | |
| 23. | S472-600364 | [3] | De speld-LENTE | |
| 24. | 39Q6-12320 | [1] | Toestel-ZON 1 | |
| 25. | 39Q6-12330 | [2] | Plaat-DUW | |
| 26. | 39Q6-12340 | [1] | KOKER | |
| 27. | S631-120001 | [1] | O-RING | |
| 28. | 39Q6-12350 | [1] | Verbinding-OLIE | |
| 29. | 39Q6-41450 | [2] | Speld-PARALLEL | |
| 30. | S109-16045D | [12] | Bout-CONTACTDOOS | |
| 31. | 39Q6-12360 | [1] | NAAMplaat | |
| 31. | 39Q6-12361 | [1] | NAAMplaat | |
| 31. | 39Q6-12362 | [1] | NAAMplaat | |
| 32. | 39Q6-41800 | [2] | KLINKNAGEL | |
| 33. | P220-430204 | [1] | Stop-HEXUITDRAAI | |
| *-1. | @ | [1] | DE EENHEID VAN DE SCHOMMELINGSmotor | ZIE 4115 |
| K1. | 39Q6-12180 | [1] | DRAGER ASSY KIT 1 | ZIE ILLUST |
| K2. | 39Q6-12250 | [1] | DRAGER ASSY KIT 2 | ZIE ILLUST |
